| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 15414A7 | COVER, CARBURETOR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 1372320 | DECAL, CARBURETOR COVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 1372329 | DECAL, CARBURETOR COVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 3 | 86271 | FLAME ARRESTOR, CARBURETOR | 86271A1 | SS |
|
$117.99 | $111.05 | 1 | |
| 4 | 18484A3 | COVER, CARBURETOR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 5 | 812776A1 | DECAL SET, COVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 6 | 863200 | FLAME ARRESTOR | 44196T1 | SS |
|
$224.99 | $211.50 | 1 | |
| 7 | 86400 | WASHER, SEALING | ACT | $1.70 | $1.66 | 1 | |||
| 8 | 826709109 | NUT, (.250-28), SILENCER ADAPTER | 20586 | SS |
|
$3.59 | $3.50 | 1 | |
| 9 | 8M0062669 | HOSE (11-1/4") | 9331512 | SS |
|
$28.49 | $27.91 | 2 | |
| 9 | 8M0086022 | HOSE, Breather (CORRUGATED) | 1589418 | SS |
|
$36.49 | $35.68 | 2 | |
| 10 | 53101 | CLAMP, VENT HOSE | NLA |
|
$0.00 | $0.00 | 4 | ||
| 11 | 97850T | ELBOW, 90 Degree, Breather - VENT HOSE | 97850 | SS |
|
$5.69 | $5.56 | OPT | |
| 11 | 47957 | CONNECTOR, VENT HOSE (STRAIGHT) | NLA |
|
$0.00 | $0.00 | OPT | ||
| 12 | 8M0071559 | GROMMET, ROCKER COVER | 52188 | SS |
|
$8.49 | $8.29 | 2 | |
| 13 | 807764A1 | CARBURETOR ASSEMBLY (MERCARB) | 9565A1 | SS |
|
$1,222.99 | $1,120.83 | 1 | |
| 14 | 70125A02 | --COVER, Choke | 70125A1 | SS |
|
$194.99 | $183.64 | 1 | |
| 15 | 33047 | --SCREW, CHOKE COVER | NLA |
|
$0.00 | $0.00 | 3 | ||
| 16 | 26995 | --LOCKWASHER, (#8) Stainless Steel, COVER SCREW | ACT | $1.10 | $1.08 | 1 | |||
| 17 | 33036 | --RETAINER, COVER SCREW | NLA |
|
$0.00 | $0.00 | 3 | ||
| 18 | 54090 | ELBOW, CARBURETOR | ACT | $18.99 | $18.66 | 1 | |||
| 19 | 97012 | STUD, FLAME ARRESTOR | ACT | $22.99 | $22.51 | 1 | |||
| 20 | 8267139 | NUT, JAM - FLAME ARRESTOR | 28941 | SS |
|
$2.59 | $2.53 | 1 | |
| 21 | 8M0113177 | STUD, (.312 x 1.500), CARBURETOR | 70236 | SS |
|
$5.49 | $5.37 | 2 | |
| 21 | 70237 | STUD, (.312-18/.312-24 x 2.620), CARBURETOR | ACT | $4.19 | $4.10 | 2 | |||
| 22 | 862902 | NUT, (.9375-24), CARBURETOR STUD | 25594 | SS |
|
$2.39 | $2.33 | 4 | |
| 23 | 20084 | WASHER, (.328 x .562 x .062), CARBURETOR STUD | ACT | $2.97 | $2.92 | 4 | |||
| 24 | 805489T | BRACKET, THROTTLE CABLE | 77456A2 | SS |
|
$85.99 | $82.64 | 1 | |
| 25 | 38525 | STUD, THROTTLE CABLE | ACT | $5.19 | $5.08 | 1 | |||
| 26 | 24664 | WASHER, (M4 x 20), THROTTLE CABLE STUD | ACT | $1.40 | $1.37 | 2 | |||
| 27 | 826709109 | NUT, (.250-28), THROTTLE CABLE STUD | 20586 | SS |
|
$3.59 | $3.50 | 1 | |
| 28 | 8079821 | GASKET, CARBURETOR TO INTAKE MANIFOLD | 701431 | SS |
|
$5.29 | $5.17 | 1 | |
| 29 | 98509 | SCREW, THROTTLE CABLE TO CARBURETOR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 30 | 8M0204666 | WASHER, (.203 x .500 x .032), THROTTLE CABLE SCREW | 56681 | SS |
|
$1.80 | $1.76 | 1 | |
| 31 | 57938 | BUSHING, THROTTLE CABLE SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 32 | 34948 | SPACER, THROTTLE CABLE SCREW | ACT | $12.29 | $12.00 | 1 | |||
| 33 | 847883 | WASHER, THROTTLE CABLE SCREW | 20128 | SS |
|
$5.20 | $5.08 | 1 | |
| 34 | 8267086 | NUT, (#10-32), THROTTLE CABLE SCREW | 20190 | SS |
|
$1.70 | $1.66 | 1 | |
| - | 11977A92 | GASKET SET | NLA |
|
$0.00 | $0.00 | 1 |
