Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 841203T COIL, Ignition ACT $363.49 $336.32 2
- 841205 DECAL SHEET, Coils And Relays, Four Sets Per Sheet NLA $0.00 $0.00 1
2 848920 SCREW, (.250-20 x 2.50) ACT $8.24 $8.12 3
3 846673 WASHER, (.265 x .500 x .060) Stainless Steel ACT $1.10 $1.08 6
4 841214002 BRACKET 8412141 SS $81.17 $77.57 1
5 841214002 BRACKET ACT $81.17 $77.57 1
6 8267098 NUT, (.250-20) Stainless Steel ACT $6.89 $6.73 3
7 45176 WASHER, (.453 x .812 x .105) Stainless Steel ACT $1.50 $1.47 1
8 99204 SCREW, (.437-14 x 1.00) Stainless Steel ACT $5.09 $4.98 1
9 840955T01 CABLE SET, Ignition - Blue Wires ACT $233.68 $216.27 1
10 828547253 --CONDUIT, (.250 Inside Diameter x 3.00 Feet Bulk), Cut As Required ACT $2.79 $2.72 AR
- 843137A01 --MARKER SET, Ignition Cables, Includes Two Each Of 1 Thru 8 Numbers ACT $32.36 $31.89 1
11 8M0114747 SPARK PLUG 810883 SS $8.89 $8.68 8
12 54676 RETAINER, Two Wire ACT $5.19 $5.08 4
13 32783 RETAINER, Three Wire ACT $4.09 $4.00 2
14 32784 RETAINER, Four Wire NLA $0.00 $0.00 2
15 99204 SCREW, (.437-14 x 1.00) Stainless Steel ACT $5.09 $4.98 2
16 45176 WASHER, (.453 x .812 x .105) Stainless Steel ACT $1.50 $1.47 2
17 840954T01 BRACKET, Controller Mount NLA $0.00 $0.00 1
18 42600A09 CONTROLLER ASSEMBLY, Mercathode 42600A3 SS $164.99 $148.38 1
19 26996 LOCKWASHER, (#10) Stainless Steel ACT $1.20 $1.18 5
20 68219 NUT, (#10-32) Stainless Steel ACT $2.99 $2.92 4
21 30164 WASHER, (.192 x .375 x .0312) Stainless Steel ACT $2.49 $2.43 2
22 8M0204718 NUT, (#10-32) Stainless Steel 826709106 SS $4.69 $4.59 2
23 62568 SCREW, (#10-16 x .375) ACT $1.10 $1.08 1
24 65208 BOOT, Insulator - Black NLA $0.00 $0.00 2
25 865181T01 HARNESS ASSEMBLY, Mercathode 865181A01 SS $43.49 $42.55 1
26 95084A9 CABLE ASSEMBLY, (91.00 Inches) Red/Purple Strip, Red/Purple Stripe ACT $30.49 $29.95 1
27 8M0207796 FUSE, 20 Ampere 79091 SS $9.09 $8.88 1
28 95084A10 CABLE ASSEMBLY, (5.00 Inches) Red, Red SS $9.49 $9.27 1
29 840945T06 HARNESS ASSEMBLY, Engine 840945T04 SS $2,615.44 $2,341.82 1
30 858754 --COVER, Fuse ACT $9.69 $9.46 2
31 832969T05 --FUSE, Mini - Tan - 5 Ampere 8329695 SS $6.69 $6.54 1
31 832969T15 --FUSE, Mini - Blue - 15 Ampere 83296915 SS $4.09 $4.00 3
31 832969T20 --FUSE, Mini - Yellow - 20 Ampere 83296920 SS $7.09 $6.93 5
31 83296930 --FUSE, Mini - Green - 30 Ampere ACT $5.49 $5.37 1
32 840984T01 BRACKET, PCM Mount ACT $229.42 $212.33 1
33 8267098 NUT, (.250-20) Stainless Steel ACT $6.89 $6.73 4
34 846673 WASHER, (.265 x .500 x .060) Stainless Steel ACT $1.10 $1.08 4
35 8M0207773 RELAY ASSEMBLY 882751A1 SS $22.69 $22.26 4
36 818967 --GROMMET ACT $3.19 $3.11 4
37 8M0214955 --BUSHING 818968 SS $2.89 $2.82 4
38 61356 NUT, (#10-32) Reduced Hex ACT $3.29 $3.21 2
39 68219 NUT, (#10-32) Stainless Steel ACT $2.99 $2.92 2
40 26996 LOCKWASHER, (#10) Stainless Steel ACT $1.20 $1.18 2
41 11178A01 BREAKER, Circuit - 50 Ampere 11178 SS $121.49 $109.31 1
42 96113 SCREW, (#10-32 x .880) Stainless Steel ACT $0.50 $0.49 2
43 72554 DECAL, Circuit Breaker ACT $1.00 $0.98 1
44 879962 CLIP, Connector ACT $1.99 $1.95 3
45 8M0185146 SOLENOID ASSEMBLY, Starter 850187T1 SS $62.49 $58.63 1
46 8M0214955 --BUSHING 818968 SS $2.89 $2.82 2
47 818967 --GROMMET ACT $3.19 $3.11 2
48 828478 SCREW, (.250-20 x 1.00) Stainless Steel ACT $2.79 $2.72 2
49 26992 LOCKWASHER, (.250) Stainless Steel ACT $1.20 $1.18 2
50 94330 NUT, (.250-20) Brass ACT $1.70 $1.66 2
51 880787 BOOT, Insulator - Yellow ACT $1.90 $1.86 1
51 880786 BOOT, Insulator - Red ACT $3.09 $3.01 3
52 8M0062940 SEAL, 6 Inches ACT $22.72 $22.40 1
53 8267098 NUT, (.250-20) Stainless Steel ACT $6.89 $6.73 2
54 846673 WASHER, (.265 x .500 x .060) Stainless Steel ACT $1.10 $1.08 2
55 8424491 BRACKET, Module Mount NLA $0.00 $0.00 1
56 841155T01 MODULE ASSEMBLY NLA $0.00 $0.00 1
57 40019111 SCREW, (M5 x 35) ACT $1.10 $1.08 3
58 843486 WASHER, (.203 x .438 x .037) Stainless Steel ACT $0.67 $0.67 3
59 879148T73 PCM, Propulsion Control Module, Programmed Control Module 840947005 SS $3,633.60 $3,253.47 1
60 828478 SCREW, (.250-20 x 1.00) Stainless Steel ACT $2.79 $2.72 3
61 65567 WASHER, (.265 x .750 x .048) Stainless Steel ACT $2.89 $2.82 3
62 8M0190980 GROMMET 834985 SS $3.89 $3.79 3
63 856954 BUSHING ACT $6.99 $6.83 3
64 859135 NUT, (.437-20) Brass/Nickel Plated ACT $6.09 $5.95 2
65 45176 WASHER, (.453 x .812 x .105) Stainless Steel ACT $1.50 $1.47 2
66 57984 STUD, (.437-14/.437-20 x 2.380) 579841 SS $19.49 $19.07 1
67 858954 CLIP, (.625), Harness Support ACT $3.99 $3.91 AR
67 883066 CLIP, (.865), Harness Support ACT $2.29 $2.24 AR
67 858755 CLIP, (1.00), Harness Support ACT $2.29 $2.24 AR
68 8M0133358 STUD, (.437-14/.437-20 x 2.060) 579203 SS $17.29 $16.94 1
- 841178A1 PARTIAL ENGINE ASSEMBLY NLA $0.00 $0.00 1
