Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 828478 SCREW, (.250-20 x 1.00) Stainless Steel ACT $2.79 $2.72 3
2 65567 WASHER, (.265 x .750 x .048) Stainless Steel ACT $2.89 $2.82 3
3 840947T18 PCM, Propulsion Control Module NLA $0.00 $0.00 1
3 8M0046380 PCM, Propulsion Control Module 840947T21 SS $3,270.30 $2,997.05 1
3 8M0046379 PCM, Propulsion Control Module 840947T19 SS $0.00 $0.00 1
3 8M0081832 PCM, Propulsion Control Module 840947T20 SS $3,571.29 $3,274.01 1
4 8M0190980 GROMMET 834985 SS $3.89 $3.79 3
5 856954 BUSHING ACT $6.99 $6.83 3
6 8M8023431 BRACKET NLA $0.00 $0.00 1
6 8M8024731 BRACKET, Dual, 1200 SCi NLA $0.00 $0.00 1
7 858755 CLIP, (1.00), Wire Harness Mount ACT $2.29 $2.24 2
8 828991T CLIP ACT $5.09 $4.98 5
9 880786 BOOT, Insulator - Red ACT $3.09 $3.01 2
10 68219 NUT, (#10-32) Stainless Steel ACT $2.99 $2.92 4
11 26996 LOCKWASHER, (#10) Stainless Steel ACT $1.20 $1.18 4
12 11178A01 BREAKER, Circuit - 50 Ampere ACT $121.49 $114.19 1
12 8M0021530 BREAKER, Circuit - 25 Ampere ACT $95.70 $92.89 1
13 72554 DECAL, Circuit Breaker, Push To Reset ACT $1.00 $0.98 2
14 34994 SCREW, (#10-32 x 1.00) Stainless Steel NLA $0.00 $0.00 4
15 30164 WASHER, (.192 x .375 x .0312) Stainless Steel ACT $2.49 $2.43 4
16 30164 WASHER, (.192 x .375 x .0312) Stainless Steel ACT $2.49 $2.43 4
17 61356 NUT, (#10-32) Reduced Hex ACT $3.29 $3.21 4
18 669954 SPACER, (.410 x 1.00 x .750) Aluminum - Black NLA $0.00 $0.00 3
19 8M0039427 BRACKET NLA $0.00 $0.00 1
20 842275 SCREW, (#10-32 x .380) Stainless Steel ACT $1.56 $1.54 2
21 816311T TIE STRAP, (8.00 Inches) ACT $0.60 $0.59 AR
21 847509 TIE STRAP, (7.50 Inches) ACT $1.59 $1.57 AR
22 889664 NUT, (1.500-18) Black Nylon ACT $6.69 $6.54 1
23 8M0034438 STUD, (.375-24/.375-16 x 2.250) 87163 SS $0.00 $0.00 3
24 8M0214963 WASHER, (.406 x .750 x .105) Stainless Steel 856774 SS $2.59 $2.53 3
25 82671013 NUT, (.375-24) Stainless Steel ACT $4.69 $4.59 3
26 859124 NUT, (#10-32) Stainless Steel ACT $18.69 $18.33 1
27 73288 WASHER, (.220 x .500 x .030) Stainless Steel ACT $1.50 $1.47 2
28 8M0024808 J CLIP 65292 SS $8.19 $8.00 1
29 87926 SCREW, (#10-32 x .500) NLA $0.00 $0.00 1
30 8M0207773 RELAY ASSEMBLY 882751A1 SS $22.69 $22.26 5
31 8M0207771 --BRACKET 828102 SS $7.39 $7.22 5
32 8M0214955 --BUSHING 818968 SS $2.89 $2.82 5
33 818967 --GROMMET ACT $3.19 $3.11 5
34 8M0204649 WASHER, (.281 x .500 x .060) Stainless Steel 29245 SS $1.20 $1.18 5
35 28667 SCREW, (.250-20 x 1.00) Stainless Steel ACT $1.50 $1.47 5
36 8M0185146 SOLENOID ASSEMBLY 850187T1 SS $62.49 $59.88 1
37 8M0214955 --BUSHING 818968 SS $2.89 $2.82 2
38 818967 --GROMMET ACT $3.19 $3.11 2
39 8M0204649 WASHER, (.281 x .500 x .060) Stainless Steel 29245 SS $1.20 $1.18 2
40 28667 SCREW, (.250-20 x 1.00) Stainless Steel ACT $1.50 $1.47 2
41 26995 LOCKWASHER, (#8) Stainless Steel ACT $1.10 $1.08 2
42 26419 NUT, (#8-32) Brass ACT $1.70 $1.66 2
43 26992 LOCKWASHER, (.250) Stainless Steel ACT $1.20 $1.18 2
44 94330 NUT, (.250-20) Brass ACT $1.70 $1.66 2
45 880787 BOOT, Insulator - Yellow ACT $1.90 $1.86 1
46 880786 BOOT, Insulator - Red ACT $3.09 $3.01 1
