| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 32722 | FUEL PUMP ASSEMBLY | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| - | 33357 | FUEL PUNP REPAIR KIT | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| - | 33358 | FUEL PUMP DIAPHRAGM KIT | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 2 | 34213 | GADKET, FUEL PUMP MOUNTING | ACT | $7.09 | $6.93 | 1,1,1,1 | |||
| 3 | 45488 | BOLT, FUEL PUMP TO CYLINDER BLOCK (5/16") | 34554 | SS |
|
$0.00 | $0.00 | 2,2,2,2 | |
| 4 | 17008 | FUEL LINE, FUEL TANK TO FUEL PUMP | 30466 | SS |
|
$0.00 | $0.00 | 1,1,1,1 | |
| 5 | 17006 | FUEL LINE, FUEL PUMP TO FUEL FILTER | 33099 | SS |
|
$0.00 | $0.00 | 1,1,1,1 | |
| 6 | 22627 | CLIP, FUEL LINE TO COIL BRACKET | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 7 | 8M0084613 | "D" WASHER, FUEL LINE CLIP SCREW | 22789 | SS |
|
$1.10 | $1.08 | 1,1,1,1 | |
| 8 | 30177 | NUT, FUEL LINE TO TEE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 9 | 30175 | SLEEVE, FUEL LINE NUT TO TEE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 10 | 33097A1 | PIPE ASSEMBLY, CHOKE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 11 | 21310 | --NUT, CHOKE PIPE TO CARBURETOR | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 12 | 21309 | --SLEEVE, CHOKE PIPE TO CARBURETOR | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 13 | 34292 | --COVERING, CHOKE PIPE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 14 | 21373 | CONNECTOR, INTAKE MANIFOLD COVER TO CHOKE PIPE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 15 | 2161 | CARBURETOR ASSEMBLY, FRONT (BC) D8 FOR BREAKDOWN | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 16 | 33122 | NUT, JAM-FLAME ARRESTOR MOUNTING STUD | NLA |
|
$0.88 | $0.87 | 2,2,2,2 | ||
| 17 | 33102 | STUD, FLAME ARRESTOR MOUNTING-CARBURETOR | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 18 | 8267139 | NUT, FLAME ARRESTOR MOUNTING STUD (BOTTOM) | 28941 | SS |
|
$2.59 | $2.53 | 2,2,2,2 | |
| 19 | 85786A1 | FLAME ARRESTOR | 33061 | SS |
|
$0.00 | $0.00 | 2,2,2,2 | |
| 20 | 22937 | WASHER, FLAME ARRESTOR MOUNTING STUD | ACT | $3.79 | $3.69 | 2,2,2,2 | |||
| 21 | 826709109 | NUT, FLAME ARRESTOR MOUNTING STUD (TOP) | 20586 | SS |
|
$3.59 | $3.50 | 2,2,2,2 | |
| 22 | 33108 | PLATE, THROTTLE-CARBURETOR | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 23 | 69022 | SCREW, THROTTLE PLATE TO CARBURETOR | 20100 | SS |
|
$1.10 | $1.08 | 4,4,4,4 | |
| 24 | 26014 | WASHER, THROTTLE PLATE TO CARBURETOR SCREW | NLA |
|
$0.00 | $0.00 | 5,5,5,5 | ||
| 25 | 847883 | WASHER, THROTTLE PLATE TO CARBURETOR SCREW | 20128 | SS |
|
$5.20 | $5.08 | 1,1,1,1 | |
| 26 | 20110 | NUT, THROTTLE PLATE TO CARBURETOR SCREW | ACT | $1.70 | $1.66 | 4,4,4,4 | |||
| 27 | 33453 | SPRING, THROTTLE RETURN-CARBURETOR (2 3/") | NLA |
|
$0.00 | $0.00 | 2,2,2, | ||
| 27 | 33453 | SPRING, THROTTLE RETURN-CARBURETOR (2 3/") | NLA |
|
$0.00 | $0.00 | ,,,1 | ||
| 27 | 35874 | SPRING, THROTTLE RETURN-CARBURETOR (4 3/4") | NLA |
|
$0.00 | $0.00 | ,,,1 | ||
| 28 | 27711 | RETAINER,INTAKE MANIFOLD COVER SCREW-THROTTLE RETURN SPRING | 33151 | SS |
|
$0.00 | $0.00 | 1,1,1, | |
| 28 | 78201 | RETAINER,INTAKE MANIFOLD C0OVER SCREW-THROTTLE RETURN SPRING | 26551 | SS |
|
$0.00 | $0.00 | ,,,1 | |
| 29 | 33460 | GASKET, CARBURETOR TO INTAKE MANIFOLD COVER | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 30 | 32876 | NIPPLE, FUEL FILTER TO CARBURETOR | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 31 | 35382A1 | FUEL FILETER ASSEMBLY, CARBURETOR | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 32 | 35157 | --BOWL, ALUMINUM-FUEL FILTER | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 33 | 33744 | --ELEMENT, FUEL FILTER | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 34 | 33746 | -- GASKET, FUEL FILETER ELEMENT | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 35 | 33745 | --GASKET, FUEL FILTER BOWL | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 36 | 33740 | TEE, FUEL FILTER TO FUEL LINES | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 37 | 17005 | FUEL LINE, FUEL FILTER TO FUEL (14 1/2") | 33098 | SS |
|
$0.00 | $0.00 | 1,1,1,1 | |
| 38 | 30177 | NUT, FUEL LINE TO TEE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 39 | 30175 | SLEEVE, FUEL LINE TO TEE NUT | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 40 | 22627 | CLIP, FUEL FILTER TO FUEL LINE TO CARBURETOR | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 41 | 22654 | SCREW, FUEL FILTER TO FUEL FILTER LINE TO CARBURETOR | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 42 | 8M0084613 | "D" WASHER, FUEL LINE CLIP SCREW | 22789 | SS |
|
$1.10 | $1.08 | 1,1,1,1 | |
| 43 | 59351 | ELBOW, FUEL FILTER TO FUEL LINE | 23125 | SS |
|
$8.79 | $8.59 | 1,1,1,1 | |
| 44 | 2166 | CARBURETOR ASSEMBLY, REAR (B) D8 FOR BREAKDOWN | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 46 | 34423 | HOSE, VENT-REAR CARBURETOR TO VENT ELBOW (6 7/8") | 32846 | SS |
|
$33.99 | $33.25 | 1,1,1,1 | |
| 46 | 34423 | HOSE, VENT-REAR CARBURETOR TO VENT ELBOW (10) | 36119 | SS |
|
$33.99 | $33.25 | ,,,1 | |
| 47 | 34423 | HOSE, VENT-FRONT CARBURETOR TO VENT ELBOW (12 5/8") | 33458 | SS |
|
$33.99 | $33.25 | 1,1,1,1 | |
| 48 | 815504206 | CLAMP, VENT HOSE ATTACHING | 35830 | SS |
|
$6.79 | $6.64 | 2,2,2,2 | |
| 49 | 20550 | STUD, CARBURETOR MOUNTING-INTAKE MANIFOLD COVER | NLA |
|
$0.00 | $0.00 | 4,4,4,4 | ||
| 50 | 25269 | NUT, CARBURETOR MOUNTING STUD | NLA |
|
$3.15 | $3.08 | 4,4,4,4 | ||
| 51 | 33091 | LEVER, THROTTLE-MANIFOLD BODY | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 52 | 98509 | SCREW, SWIVEL JOINT TO THROTTLE LEVER | 22958 | SS |
|
$0.00 | $0.00 | 1,1,1,1 | |
| 53 | 33104 | SWIVEL JOINT, THROTTLE LEVER | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 54 | 33109 | BUSHING, SWIVEL JOINT TO THROTTLE LEVER SCREW | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 55 | 847883 | WASHER, SWIVEL JOINT TO THROTTLE LEVER SCREW | 20128 | SS |
|
$5.20 | $5.08 | 2,2,2,2 | |
| 56 | 8267086 | NUT, SWIVEL JOINT TO THROTTLE LEVER SCREW | 20190 | SS |
|
$1.70 | $1.66 | 1,1,1,1 | |
| 57 | 73656 | SCREW, REMOTE CONTROL CABLE TO THROTTLE LEVER | 24233 | SS |
|
$0.00 | $0.00 | 1,1,1,1 | |
| 58 | 32818 | BUSHING, REMOTE CONTROL CABLE TO THROTTLE LEVER SCREW | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 59 | 847883 | WASHER, REMOTE CONTROL CABLE THROTTLE LEVER SCREW | 20128 | SS |
|
$5.20 | $5.08 | 2,2,2,2 | |
| 60 | 8267086 | NUT, REMOTE CABLE TO THROTTLE LEVER SCREW | 20190 | SS |
|
$1.70 | $1.66 | 1,1,1,1 | |
| 61 | 88488 | SCREW, THROTTLE PLATE SWIVEL JOINT | 31471 | SS |
|
$0.00 | $0.00 | 1,1,1,1 | |
| 62 | 25168 | NUT, JAM-THROTTLE PLATE SWIVEL JOINT | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 63 | 33123 | SCREW, SWIVEL JOINT AND SLIP JOINT TO THROTTLE PLATE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 64 | 847883 | WASHER, SWIVEL JOINT AND SLIP JOINT TO THROTTLE PLATE SCREW | 20128 | SS |
|
$5.20 | $5.08 | 2,2,2,2 | |
| 65 | 33109 | BUSHING, SWIVEL JOINT AND SLIP JOINT TO THROTTLE PLATE SCREW | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 66 | 33105 | SLIP JOINT, THROTTLE PLATE (REAR CARBURETOR) | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 67 | 33104 | SWIVEL JOINT, THROTTLE PLATE | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 68 | 20110 | NUT, SWIVEL JOINT AND SLIP JOINT TO THROTTLE PLATE SCREW | ACT | $1.70 | $1.66 | 1,1,1,1 | |||
| 69 | 33103 | LINK ROD CABURETOR THROTTLE PLATE TO CARBURETOR THROTTLE PLT | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 70 | 25168 | NUT,JAM-CARBURETOR THROTTLE PLATE LINK ROD | NLA |
|
$0.00 | $0.00 | 2,2,2,2 | ||
| 71 | 26953 | COTTER PIN, CARBURETOR THROTTLE PLATE LINK ROD | ACT | $4.19 | $4.10 | 1,1,1,1 | |||
| 72 | 20028 | WASHER, CARBURETOR THROTTLE PLATE LINK ROD | ACT | $1.80 | $1.76 | 1,1,1,1 | |||
| 73 | 20099 | SPRING, CARBURETOR THROTTLE PLATE LINK ROD | ACT | $5.49 | $5.37 | 1,1,1,1 | |||
| 74 | 37892 | SCREW,SLIP JOINT TO THROTTLE PLATE | NLA |
|
$1.32 | $1.29 | 1,1,1,1 | ||
| 75 | 33109 | BUSHING, SLIP JOINT TO THROTTLE PLATE SCREW | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 76 | 33105 | SLIP JOINT, THROTTLE PLATE (FRONT CARBURETOR) | NLA |
|
$0.00 | $0.00 | 1,1,1,1 | ||
| 77 | 847883 | WASHER, SLIP JOINT TO THROTTLE PLATE SCREW | 20128 | SS |
|
$5.20 | $5.08 | 2,2,2,2 | |
| 78 | 8267086 | NUT, SLIP JOINT TO THROTTLE PLATE SCREW | 20190 | SS |
|
$1.70 | $1.66 | 1,1,1,1 |
